solar street light | SYB series
OVERVIEW
solar street light ( SYB series ) are built with high-quality materials and advanced technology. They consist of solar panels, batteries, LED lights, and intelligent controllers. The solar panels absorb sunlight during the day, converting it into electrical energy that is stored in the batteries. The LED lights are then powered by the stored energy, providing bright and reliable illumination during the night.
TYPICAL PARAMETERS
product name: | solar street light & SYB series | product brand: | QUEENDOM |
Applicable debugging: | 6-8 meters | Lamp body material: | aluminum |
Lamp power: | 30-80 W | Irradiation range: | 10-30 meters |
Light source chip: | LED light source | Lighting time: | ≥ 12 hours |
Rainy duration: | 7-15 days | Wind resistance level: | 40m/min |
Applicable road width: | 4-6 meters | Seismic rating: | 8magnitude |
Operating temperature: | 25-65℃ | Scope of application: | Municipal roads parks and scenic areas sidewalks |
PRODUCT
Description | Power | material | Battery capacity | Solar panel power | leds | Effect LM/W | Initial IV/LM | Color | CRI | IP | View Angle | Service life | product size(mm) | Part No. |
QDSOL-SYB-30WA | 30 | Aluminum | 3.2V 40AH | 6V/35W | EMC LEDs | 90-120lm/W | 3100 | 3000 | Ra≥70 | IP67 | 120° | 30000H | 830*300*145mm | SOLS1037 |
QDSOL-SYB-40WA | 40 | Aluminum | 3.2V 50AH | 6V/40W | EMC LEDs | 90-120lm/W | 4000 | 3000 | Ra≥70 | IP67 | 120° | 30000H | 909*370*145mm | SOLS1038 |
QDSOL-SYB-60WA | 60 | Aluminum | 3.2V 60AH | 6V/45W | EMC LEDs | 90-120lm/W | 7900 | 3000 | Ra≥70 | IP67 | 120° | 30000H | 1089*300*145mm | SOLS1039 |
QDSOL-SYB-80WA | 80 | Aluminum | 3.2V/90AH | 6V/80W | EMC LEDs | 90-120lm/W | 8000 | 3000 | Ra≥70 | IP67 | 120° | 30000H | 1200*400*145mm | SOLS1040 |
QDSOL-SYB-30WC | 30 | Aluminum | 3.2V 40AH | 6V/35W | EMC LEDs | 90-120lm/W | 3100 | 6000 | Ra≥70 | IP67 | 120° | 30000H | 830*300*145mm | SOLS1041 |
QDSOL-SYB-40WC | 40 | Aluminum | 3.2V 50AH | 6V/40W | EMC LEDs | 90-120lm/W | 4000 | 6000 | Ra≥70 | IP67 | 120° | 30000H | 909*370*145mm | SOLS1042 |
QDSOL-SYB-60WC | 60 | Aluminum | 3.2V 60AH | 6V/45W | EMC LEDs | 90-120lm/W | 7900 | 6000 | Ra≥70 | IP67 | 120° | 30000H | 1089*300*145mm | SOLS1043 |
QDSOL-SYB-80WA | 80 | Aluminum | 3.2V/90AH | 6V/80W | EMC LEDs | 90-120lm/W | 8000 | 6000 | Ra≥70 | IP67 | 120° | 30000H | 1200*400*145mm | SOLS1044 |
FEATURES
- Efficient Solar Panels: Our solar street lights are equipped with highly efficient solar panels that maximize the absorption of sunlight, ensuring optimal energy conversion.
- Long-lasting Batteries: The batteries used in our lights have a high capacity and long lifespan, allowing for reliable performance and extended operation hours.
- Energy-saving LED Lights: The LED lights utilized in our street lights are energy-efficient, providing bright illumination while consuming minimal power.
- Intelligent Controllers: Our lights are equipped with intelligent controllers that optimize the charging and discharging of the batteries, ensuring efficient energy utilization.
- Weather-resistant Design: The street lights are designed to withstand harsh weather conditions, making them suitable for various outdoor environments.
BENEFITS
- Energy Saving: By utilizing solar energy, our street lights significantly reduce electricity costs and contribute to energy conservation.
- Environmentally Friendly: Solar street lights produce zero carbon emissions and help reduce the reliance on non-renewable energy sources, promoting a greener environment.
- Cost-effective: Once installed, solar street lights require minimal maintenance and have low operational costs, making them a cost-effective lighting solution in the long run.
- Easy Installation: Our lights are designed for easy installation, without the need for extensive wiring or electrical connections.
- Enhanced Safety: Well-illuminated streets contribute to improved safety by reducing the risk of accidents and providing a secure environment for pedestrians and drivers.
INSTALLATION
The installation process of our solar street lights is straightforward. First, determine the suitable location for the lights, considering factors such as sunlight exposure and the area to be illuminated. Once the location is identified, securely mount the lights on poles or structures using the provided brackets. Ensure that the solar panels are properly angled to receive maximum sunlight. Finally, connect the components as per the provided instructions and switch on the lights. Professional assistance may be sought for larger installations or complex setups.
APPLICATION
solar street light are versatile and can be used in various outdoor settings. Some common applications include:
– Residential Areas: Illuminating residential streets, pathways, and gardens.
– Commercial Areas: Lighting up parking lots, shopping centers, and business districts.
– Public Spaces: Providing lighting in parks, plazas, and playgrounds.
– Rural Areas: Enhancing visibility on rural roads and remote villages.
– Security Lighting: Enhancing security by illuminating dark areas and deterring potential threats.
