LED Grow Light & CK series

Name: LED Grow Light & CK series
Brand: QUEENDOM

Bar -shaped plant lamp & CK series
Light source type: SMD LED
Power: 240W-600W
Voltage: 85V-180V/160-265V/50-60Hz
Color λD (NM): 6000K/3000K/Red 660NM
Light effect: 100LM/W
Protection level: IP54
Lighting angle: 120 °
Power factor: ≥0.9
PPFD/Umol/J: 2.3-3.0 Umol/J
Material: pure aluminum plate material
Life:> 50000h

Description

LED Grow Light & CK series

OVERVIEW

The long bars & CK series is a purchase of integrated high -power design. The integrated plant growth light adopts an integrated design. The structure is simple and the installation is convenient. It does not require additional assembly steps. LED long bars plant lights, special long bars of greenhouses, LED plant growth light factories

PRODUCT

PRODUCT	RANK NO.	NOMINAL λd(nm)		SIZE	POWER	VOLTAGE	TYPICAL（CCT/k)		TYPICAL WAVELENGTH (nm)		RITIO	TYPICAL FLUX		IP	TYPICAL	BASE	PART NUMBER
PRODUCT	RANK NO.	MIN	MAX	(mm)	(W)	(VF/V)	MIN	MAX	MIN	MAX	（%）	EFFECT (LM/W)	PPFD/UMOL/J	IP	DEG	BASE	PART NUMBER
PG240RBA1	PG0701	300	730	1030x81x56	240	110	N/A	N/A	450	660	2；1	120lm/w	2.6	65↑	135	/	9405500000PG0801
PG480RBA1	PG0702	300	730	1030x81x56	480	110	N/A	N/A	450	660	2；1	120lm/w	2.6	65↑	135	/	9405500000PG0802
PG240WWRA1	PG0703	300	730	1030x81x56	240	110	3000	6000	660	680	4.5；4.5：1	165lm/w	2.6	65↑	135	/	9405500000PG0803
PG480WWRA1	PG0704	300	730	1030x81x56	480	110	3000	6000	660	680	4.5；4.5：1	165lm/w	2.6	65↑	135	/	9405500000PG0804
PG240WWRIA1	PG0705	300	730	1030x81x56	240	110	3000	6000	660	730	4.0：4.0：1：1	165lm/w	2.6	65↑	135	/	9405500000PG0805
PG480WWRIA1	PG0706	300	730	1030x81x56	480	110	3000	6000	660	730	4.0：4.0：1：1	165lm/w	2.6	65↑	135	/	9405500000PG0806
PG240RBA2	PG0707	300	730	1030x81x56	240	220	N/A	N/A	450	660	2；1	120lm/w	2.6	65↑	135	/	9405500000PG0807
PG480RBA2	PG0708	300	730	1030x81x56	480	220	N/A	N/A	450	660	2；1	120lm/w	2.6	65↑	135	/	9405500000PG0808
PG240WWRA2	PG0709	300	730	1030x81x56	240	220	3000	6000	660	680	4.5；4.5：1	165lm/w	2.6	65↑	135	/	9405500000PG0809
PG480WWRA2	PG0710	300	730	1030x81x56	480	220	3000	6000	660	680	4.5；4.5：1	165lm/w	2.6	65↑	135	/	9405500000PG0810
PG240WWRIA2	PG0711	300	730	1030x81x56	240	220	3000	6000	660	730	4.0：4.0：1：1	165lm/w	2.6	65↑	135	/	9405500000PG0811
PG480WWRIA2	PG0712	300	730	1030x81x56	480	220	3000	6000	660	730	4.0：4.0：1：1	165lm/w	2.6	65↑	135	/	9405500000PG0812

FEATURES

Material: It is made of high -quality aluminum alloy and has good heat dissipation.

Spectrum: The full spectrum or specific spectrum required for plants can be provided, such as red and blue light.

Lighting efficiency: Transparent PC coverage of light transparency is 94-96%, and the light diffusion large striped PC cover light transparent light is 90-92%. Light diffusion PC cover light light 85-88%

Flame retardant level: 94-v2 or 94-v0

Installation method: You can choose to install a variety of installation methods such as hanging, fixing or surface installation.

Spectrum range: Different choices such as full spectral spectrum, red light and blue light spectrum can be provided according to demand.

Entering voltage: standard 110V, 220V AC power supply, suitable for family and offices and other environments.

BENEFITS

Provide appropriate light conditions: provide appropriate spectrals and light intensity, help plants perform photosynthesis, and promote the healthy growth of plants. Energy efficient.

The long life can reach more than 50,000 hours,

Excellent heat dissipation performance: The lamps use high -quality heat dissipation materials, which have good heat dissipation performance and can ensure the long -term stable work of the lamp.
