gu5.3 led spotlight|SD01DC SERIES
OVERVIEW
gu5.3 led spotlight is one of the models in the Queendom SD01DC series. gu5.3 led spotlight (gu5.3 led bulb) is a kind of LED light-emitting diode that uses
The light source of GU5.3 led spot; gu5.3 led spotlight usually has a voltage of DC12V/24V or AC110/220V. The power is mainly from 3W-15W.
PRODUCT
Model | Power | Input | Light | Luminous | Color | Color | Beam | Lamp holder | Size | Weight | Part No. |
Consumption | Voltage | effect | flux | temperature | Rendering | Angle | (mm) | (kg) | |||
(W) | (Vac) | (W/LM) | (lm) | (K) | (Ra) | (Deg) | |||||
QDBTEGU5.3S3WVD1 | 3 | DC12 | 85↑ | 300 | 3,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G51 |
QDBTEGU5.3S3WTD1 | 3 | DC12 | 85↑ | 300 | 4,100 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G52 |
QDBTEGU5.3S3WRD1 | 3 | DC12 | 85↑ | 300 | 5,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G53 |
QDBTEGU5.3S3WQD1 | 3 | DC12 | 85↑ | 300 | 5,700 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G54 |
QDBTEGU5.3S3WPD1 | 3 | DC12 | 85↑ | 300 | 6,500 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G55 |
QDBTEGU5.3S5WVD1 | 5 | DC12 | 85↑ | 490 | 3,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G56 |
QDBTEGU5.3S5WTD1 | 5 | DC12 | 85↑ | 490 | 4,100 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G57 |
QDBTEGU5.3S5WRD1 | 5 | DC12 | 85↑ | 490 | 5,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G58 |
QDBTEGU5.3S5WQD1 | 5 | DC12 | 85↑ | 490 | 5,700 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G59 |
QDBTEGU5.3S5WPD1 | 5 | DC12 | 85↑ | 490 | 6,500 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G60 |
QDBTEGU5.3S9WVD1 | 9 | DC12 | 85↑ | 860 | 3,000 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G61 |
QDBTEGU5.3S9WTD1 | 9 | DC12 | 85↑ | 860 | 4,100 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G62 |
QDBTEGU5.3S9WRD1 | 9 | DC12 | 85↑ | 860 | 5,000 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G63 |
QDBTEGU5.3S9WQD1 | 9 | DC12 | 85↑ | 860 | 5,700 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G64 |
QDBTEGU5.3S9WPD1 | 9 | DC12 | 85↑ | 860 | 6,500 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G65 |
QDBTEGU5.3S12WVD1 | 12 | DC12 | 85↑ | 1,080 | 3,000 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G66 |
QDBTEGU5.3S12WTD1 | 12 | DC12 | 85↑ | 1,080 | 4,100 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G67 |
QDBTEGU5.3S12WRD1 | 12 | DC12 | 85↑ | 1,080 | 5,000 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G68 |
QDBTEGU5.3S12WQD1 | 12 | DC12 | 85↑ | 1,080 | 5,700 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G69 |
QDBTEGU5.3S12WPD1 | 12 | DC12 | 85↑ | 1,080 | 6,500 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G70 |
QDBTEGU5.3S3WVD1 | 3 | DC24 | 85↑ | 300 | 3,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G71 |
QDBTEGU5.3S3WTD1 | 3 | DC24 | 85↑ | 300 | 4,100 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G72 |
QDBTEGU5.3S3WRD1 | 3 | DC24 | 85↑ | 300 | 5,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G73 |
QDBTEGU5.3S3WQD1 | 3 | DC24 | 85↑ | 300 | 5,700 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G74 |
QDBTEGU5.3S3WPD1 | 3 | DC24 | 85↑ | 300 | 6,500 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G75 |
QDBTEGU5.3S5WVD1 | 5 | DC24 | 85↑ | 490 | 3,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G76 |
QDBTEGU5.3S5WTD1 | 5 | DC24 | 85↑ | 490 | 4,100 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G77 |
QDBTEGU5.3S5WRD1 | 5 | DC24 | 85↑ | 490 | 5,000 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G78 |
QDBTEGU5.3S5WQD1 | 5 | DC24 | 85↑ | 490 | 5,700 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G79 |
QDBTEGU5.3S5WPD1 | 5 | DC24 | 85↑ | 490 | 6,500 | 80 ↑ | 120 | GU 10 | 50X58 | 1.11 | SD01G80 |
QDBTEGU5.3S9WVD1 | 9 | DC24 | 85↑ | 860 | 3,000 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G81 |
QDBTEGU5.3S9WTD1 | 9 | DC24 | 85↑ | 860 | 4,100 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G82 |
QDBTEGU5.3S9WRD1 | 9 | DC24 | 85↑ | 860 | 5,000 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G83 |
QDBTEGU5.3S9WQD1 | 9 | DC24 | 85↑ | 860 | 5,700 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G84 |
QDBTEGU5.3S9WPD1 | 9 | DC24 | 85↑ | 860 | 6,500 | 80 ↑ | 120 | GU 10 | 60X50 | 1.2 | SD01G85 |
QDBTEGU5.3S12WVD1 | 12 | DC24 | 85↑ | 1,080 | 3,000 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G86 |
QDBTEGU5.3S12WTD1 | 12 | DC24 | 85↑ | 1,080 | 4,100 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G87 |
QDBTEGU5.3S12WRD1 |
12 | DC24 | 85↑ | 1,080 | 5,000 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G88 |
QDBTEGU5.3S12WQD1 | 12 | DC24 | 85↑ | 1,080 | 5,700 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G89 |
QDBTEGU5.3S12WPD1 | 12 | DC24 | 85↑ | 1,080 | 6,500 | 80 ↑ | 120 | GU 10 | 70X48 | 1.2 | SD01G90 |
FEATURES
Product material: aluminum body radiator + PC plastic lamp holder.
Adaptable light source: imitation lumens high-power LED or Smd led (COB light source optional)
Adapting lens: Imitation lumen one-piece lens.
Lens angle: 15-60 degrees
Surface color: silver + white PC lamp head.
Product diameter: 48mm; COB light source 50mm;
BENEFITS
GU5.3 base: easy to use, simple to install, suitable for lamps with GU5.3 lamp base.
gu5.3 led spotlight has a super long life, which can generally reach 50,000 hours;
Environmentally friendly and healthy: LED lamps do not contain harmful substances, such as mercury, lead, etc.
The metal shell can effectively dissipate heat and ensure long-term stable operation of the lamp.
APPLICATION
Home lighting: in various rooms such as living room, bedroom, dining room, etc.
Commercial lighting: various commercial places, such as shopping malls, hotels, restaurants, museums, etc.
Hotel lighting: It can be used for lighting in hotel lobbies, guest rooms and other areas to create a high-end and comfortable lighting atmosphere and enhance the hotel’s image.
Exhibition lighting: Suitable for lighting in museums, art exhibitions and other places, which can highlight the characteristics of exhibits and display artistic charm.
Catering lighting: It can be used for lighting in restaurants, cafes and other places to create a comfortable and romantic dining environment and increase customer experience.
