Flood Light & XG module series

Flood Light & XG module series

LED TYPE: SMD LEDs

Power: 50W-300W

Voltage: AC 85V-265V/50-60Hz

CCT(K): 3000k/6000k/

Effect: 110-130+ LM/W

CRI: 70 ↑

Housing: Aluminum

Protection level: IP65

Angle: 120-150 °

PF: ≥0.9

Life:> 50000h

Categories: , Tag:

Flood Light & XG module series

OVERVIEW

Flood Light  is a common outdoor floodlight led;Flood Lights fixture that emits light at a wide angle and can illuminate a wider area outdoor floodlight；

PRODUCT

PRODUCT RANK NO. NOMINAL SIZE POWER  VOLTAGE FLUX EFFECT CRI IP PART NUMBER
（CCT/k) (mm) (W) (VF/V) (lm) (LM/W)  (Ra)
FLXG50WVA1 FL101 3000 186*40*222 50 100-265 5500 100-130 80↑ 65 9405500000FL101
FLXG100WVA1 FL102 3000 265*220*50 100 100-265 11000 100-130 80↑ 65 9405500000FL102
FLXG150WVA1 FL103 3000 290*240*50 150 100-265 16500 100-130 80↑ 65 9405500000FL103
FLXG200WVA1 FL104 3000 375*328*60 200 100-265 22000 100-130 80↑ 65 9405500000FL104
FLXG300WVA1 FL105 3000 400*360*65 300 100-265 33000 100-130 80↑ 65 9405500000FL105
FLXG50WTA1 FL106 4000 186*40*222 50 100-265 5500 100-130 80↑ 65 9405500000FL106
FLXG100WTA1 FL107 4000 265*220*50 100 100-265 11000 100-130 80↑ 65 9405500000FL107
FLXG150WTA1 FL108 4000 290*240*50 150 100-265 16500 100-130 80↑ 65 9405500000FL108
FLXG200WTA1 FL109 4000 375*328*60 200 100-265 22000 100-130 80↑ 65 9405500000FL109
FLXG300WTA1 FL110 4000 400*360*65 300 100-265 33000 100-130 80↑ 65 9405500000FL110
FLXG50WPA1 FL111 6000 186*40*222 50 100-265 5500 100-130 80↑ 65 9405500000FL111
FLXG100WPA1 FL112 6000 265*220*50 100 100-265 11000 100-130 80↑ 65 9405500000FL112
FLXG150WPA1 FL113 6000 290*240*50 150 100-265 16500 100-130 80↑ 65 9405500000FL113
FLXG200WPA1 FL114 6000 375*328*60 200 100-265 22000 100-130 80↑ 65 9405500000FL114
FLXG300WPA1 FL115 6000 400*360*65 300 100-265 33000 100-130 80↑ 65 9405500000FL115

FEATURES

1. character and application

This product is made of all-aluminum material, which is durable and has good heat dissipation, thus effectively prolonging the service life of the product. The installation is convenient and simple, and the installation method can be freely selected according to the use requirements. It can be installed on the lamp pole bracket, wall, ceiling, workshop, etc., and can also be directly connected to the ground or placed on the lamp placement platform with the bracket.

2. Light source characteristics

Adopt domestic famous brand SMD-2835 light source, which has high brightness, small light attenuation and longer service life..

3. Power supply characteristics

Adopt high-stability isolated constant current power supply scheme, it has the characteristics of over-temperature protection, wide voltage range, high power factor, high efficiency and good heat dissipation effect.

4. Heat sink feature

Adopt high-purity aluminum radiator with high thermal conductivity. The radiator is specially designed, taking aerodynamics and hydromechanics into full consideration, maximizing the heat dissipation area and the efficiency of heat exchange with cold and hot air, so that the heat generated by the light source can be efficiently emitted and the reasonable temperature can be maintained, thus ensuring the stability of the product function and prolonging its service life.

5. Installs Way

Adopt lamp pole installation or wall installation

APPLICATION

It is suitable for lighting in large and medium-sized gathering places such as stadiums, stadiums, large squares, stations, parks, parking lots, etc. It can also be installed on walls or ceilings as indoor lamps for lighting workshops, warehouses or construction teams.

INSTALLATION

The working voltage of the product is AC100V-265V 50/60Hz. Do not exceed the working voltage range.
As the lamp is plastic PC lens which is easy to damage, please handle it with care and do not put it under heavy pressure when handling and
Installation instructions:
1. When installing lamps and lanterns, the wiring must be tightly sealed to prevent
the risk of leakage and short circuit of water. Do not electrify during wiring..
2.When external power lines are connected, corresponding waterproof and leakage prevention measures must be taken.
3.It shall not violate any fire regulations when used the
4.Please find professional electrician for installation. The cable should be 75-1mm2 three-core cable ,the brown wire is” L” wire, the blue wire is “N”wire, and the yellow-green wire is the “PE”.
