The image shows 5mm bi-level indicator LEDs of China QUEENDOM Company.

Bi-level-5mm

FEATURES
● Surface mount type
● High efficiency
● Low power consumption
● Versatile mounting on P.C. board or panel
● Moisture sensitivity level: 3
● RoHS compliant

Category: Circuit Board Indicator LED

Description

Product No.	Chip Material	Emitting Color	λp (nm) / x	λd (nm) / y	VF (V)	IF=mA	ΦV (lm)	Viewing Angle 2θ ½	Lens Color	Part No.
Qd-CBI5R12	AlGaInP	Super Bright Red	632	624	2-2.4	20	210-350	60	Red Diffused	8541401000TH16
Qd-CBI5O12	AlGaInP	Super Bright Orange	610	605	2-2.4	20	90-160	60	Orange Diffused	8541401000TH17
Qd-CBI5Y12	AlGaInP	Super Bright Yellow	592	590	2-2.4	20	210-350	60	Yellow Diffused	8541401000TH18
Qd-CBI5G12	AlGaInP/GaAs	Super Yellow Green	573	571	2-2.4	20	70-120	60	Green Diffused	8541401000TH19
Qd-CBI5B12	InGaN	Blue	468	470	3.2-3.6	20	350-600	60	Blue Diffused	8541401000TH20
