The image shows 5mm single level indicator LEDs of China QUEENDOM Company.

Single level-3mm

FEATURES
● Surface mount type
● High efficiency
● Low power consumption
● Versatile mounting on P.C. board or panel
● Moisture sensitivity level: 3
● RoHS compliant

Category: Circuit Board Indicator LED

Description

Product No.	Chip Material	Emitting Color	λp (nm) / x	λd (nm) / y	VF (V)	IF=mA	ΦV (lm)	Viewing Angle 2θ ½	Lens Color	Part No.
Qd-CBI3R11	AlGaInP	Super Bright Red	632	624	2-2.4	20	160-270	80	Red Diffused	8541401000TH01
Qd-CBI3O11	AlGaInP	Super Bright Orange	610	605	2-2.4	20	90-160	80	Orange Diffused	8541401000TH02
Qd-CBI3Y11	AlGaInP	Super Bright Yellow	592	590	2-2.4	20	90-160	80	Yellow Diffused	8541401000TH03
Qd-CBI3G11	AlGaInP/GaAs	Super Yellow Green	573	571	2-2.4	20	90-160	80	Green Diffused	8541401000TH04
Qd-CBI3B11	InGaN	Blue	468	470	3.2-3.6	20	460-780	60	Blue Diffused	8541401000TH05
